Products / ScreenBeam 1100 EDU

ScreenBeam 1100

This product is end-of-life and replaced by ScreenBeam 1100 Plus.

The ScreenBeam 1100 is a wireless presentation platform designed for the conference room.

Product Highlights

Wireless display receiver for Windows, Mac/iOS and ChromeOS
Duplicate or extend screen mirroring in high definition
Multi-network architecture with hotspot Wi-Fi for guest users
Compatible with Interactive Flat Panels (IFP) for Windows touchback
Deploy, manage, oversee and log activities with ScreenBeam CMS Enterprise

Download Data Sheet

Request A Trial

Schedule A Demo

App-less and dongle-less screen mirroring

Screen sharing from any device without the need to download an app or keep dongle nearby. ScreenBeam leads with OS-native Wi-Fi Miracast for familiarity and mitigate user training.

Extended desktop

Windows users can mirror desktop or extend screen to ensure content privacy.

Touch display support

Windows users can markup content directly on room displays, instantly capturing changes in Microsoft Office 365 applications.

Multi-view

Teachers can display up to four student device screens simultaneously making it easy for classroom collaboration and discussion.

Signage Player

Idle displays in classrooms and meeting spaces can be optimized to convey information with integrated HTML-based digital signage capability.

Centralized Management

ScreenBeam CMS Enterprise included for monitor, manage, and update.

Learn More

Compatible OS/Device

Miracast: Windows 11/10 and Android
Airplay: MacOS 11+ and iOS 13+
Google Cast: ChromeOS/Chrome 98+ and Android 8+

Audio & Video Specifications

Native protocol: Miracast, Airplay, Google Cast
Video: H.264 compression
Audio: LPCM 2.0
Resolution: Up to 4K30²
Protection: HDCP 2.x³

Network Specifications

Ethernet: 1000Base-T RJ-45 LAN
Wireless (Miracast P2P1 & Wi-Fi Hotspot): 802.11ac 3×3 MIMO Dual-band 5GHz
Wireless (Infrastructure): 802.11ac 2×2 MIMO 2.4GHz and 5GHz (DFS)
BLE (Discovery): 2402-2480MHz
Authentication Protocol: IEEE 802.1x, WPA-PSK (TKIP), WPA2-PSK (AES), PEAP-MSCHAPv2, EAP-TLS

Hardware Specifications

Interfaces: 1 x HDMI® Output, 1 x RJ-45, 1 x USB 3.0 Host Type-A, 2 x USB 2.0 Host Type-A, 1 x Analog 3.5mm Audio, 1 x DC Power Jack
Power: Input 12VDC 3A, Consumption: 8.4W Typical 24.8W Peak
Temperature: Operating 0* – 40*C (32* – 104*F), Storage -20* – 85*C (-4* – 185*F)
Humidity: Operating 20-80% non-condensing, Storage 10-90% non-condensing

Dimensions

Size: W 8.66 in x D 5.66 in x H 1.99 in (220mm x 144mm x 50.5mm)
Weight: 1lb 4oz (471.74g)

Certifications

Compliant Standards: FCC, RED, RoHS, UL

Miracast P2P requires device with Wi-Fi and Intel 802.11 AC/AX Wi-Fi or equivalent is recommended.
Display resolution and quality depend on Wi-Fi and or LAN network condition.
Content protection only available for Miracast protocol.

Document Name

Download

User Manual

Download

Quick Start Guide

Download

Wall Mounting Template

Download

Case Drawing

Download

How To Connect

Learn More

Current Release

Version: 11.0.13.8

Release date: 2023, Aug 13
Changes since 11.0.13.0
Improvements and fixes
- Improved system stability
- Fixed Airplay mirroring is slow to respond a connection request
- Fixed issue where CMS Enterprise’s generated USB provisioning config file does not apply settings properly
- Fixed issue where sometimes the receiver cannot connect to CMS Enterprise or is showing offline
- Fixed issue where wireless infrastructure connection with PEAP fails after a reboot
- Improved the PIN timeout display period for MacOS/iOS
- Enabled French language and EU format for the on-screen date/clock
- Fixed screen may freeze when switching between Miracast devices
- Fixed receiver cannot connect to CMS Enterprise after firmware upgrade
- Fixed SPCMS port returns to default value after the receiver is reset from CMS Enterprise
- Fixed digital signage cannot resume after a Miracast session ended
- Fixed firmware update may fail, and requires reboot before update as a workaround
- Fixed issue where the background image and screensaver image cannot be changed
- Fixed Windows Miracast fails to connect if TV/projector resolution is 1920×1200 or higher

Download
